Jiaxing Join Fasteners Co.,Ltd. supply a wide range of DIN976 Threaded Rod. You can always rely on our team for a premium-quality, competitive pricing, on-time delivery, one-stop buy business partnership. All products are manufactured to right specification and high quality standard.
DIN976 is the most economical and most common form of Threaded Rod. 6G thread requirement. Typically used by the plumbing and contracting trades. Used in maintenance departments in various applications. Plain Finish, or bare metal finish which may contain a light coating of oil. Zinc Clear offers a modest amount of corrosion resistance.
| Dimensions: | DIN 976 |
| Material and Mechanical: | ISO 898-1; Class 8.8 or 10.9 |
| Threads: | 6g per ISO 724; ISO 965-1 |
| Finish: | Light Protective Oil or Zinc Clear |
| Head Marking: | Marked with predetermined color on rod end |
| Grade: | 8.8 or 10.9 |
| Type: | Threaded Rod |
| Test Reports: |
The MTR must have documented lot traceability, dimensional results, full chemical test results and full mechanical test results to the specification(s) below. |
|
|
|||||||||||||||
Type B DIN 78 - K type ends (only for nominal lengths of 500 mm or less)
|
Thread Size d |
M2 | M2.5 | M3 | (M3.5) | M4 | M5 | M6 | M8 | M10 | M12 | (M14) | M16 | (M18) | M20 | (M22) | ||
| P | Pitch | coarse thread | 0.4 | 0.45 | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 | 2.5 | 2.5 |
| Fine thread,1 | - | - | - | - | - | - | - | 1 | 1.25 | 1.25 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | ||
| Fine thread,2 | - | - | - | - | - | - | - | - | 1 | 1.5 | - | - | - | - | - | ||
|
Thread Size d |
M24 | (M27) | M30 | (M33) | M36 | (M39) | M42 | (M45) | M48 | (M52) | M56 | (M60) | M64 | (M68) | M72 | ||
| P | Pitch | coarse thread | 3 | 3 | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.5 | 5 | 5 | 5.5 | 5.5 | 6 | 6 | - |
| Fine thread,1 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 6 | ||
| Fine thread,2 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ||
Price term: FOB,CIF,CFR,EXW,DDP,DDU.
Lead time: Normal 45-60 days.
Packing way: Packing in bundle wrapped, palletized.
Payment terms: TT, we offer our close clients flexible payment terms and financial solution.
Dial number +86-573-83772218 or email to bob@jjbfasteners.com, your request will be promptly replied.
Address
Zhifu Centre,Bldg. No.15-1304,1305,Xiuzhou, Jiaxing, Zhejiang, China
Tel / WhatsApp
We stand behind our products. All products are manufactured to right specification and high quality standard. Any items found defective or in shortage , an immediate investigation will be conducted and corrective action report will be issued. Claims and returns are given a nice care here.
You can always rely on our team for a premium-quality, competitive pricing, on-time delivery, one-stop buy business partnership. We have over 18 years experience in exporting various kinds of carbon steel, stainless steel, Bi-Metal fasteners.
Dial number 0086 573 83772218 or email to sales@jjbfasteners.com, your request will be promptly replied.
We rigidly carry out quality control to each step of production:
